General Description
GL3820 General Description
This integrated circuit provides all video switching allowing connections between the peri TV plug and video sections in the TV set.
GL3820 Maximum Ratings
| RATING |
SYMBOL |
VALUE |
UNIT |
| Supply Voltage |
Vcc |
18 |
V |
| Operating Temperature with Load > 150W with Load = 75W |
Topr |
-10 to + 100 -10 to + 70 |
`` |
| Junction Temperature |
Tj |
-40 to + 150 |
`` |
| Storage Temperature |
Tstg |
-40 to + 150 |
`` |
| Minimum DC Load Resistor P6 Minimum DC Load Resistor P2 |
600 75 |
|
GL3820 Features
• 1 Video Output 75Ù 1 VPP No Switched
• 1 Switched Video Output 2 VPP
• Video Cross Talk : 50 dB Typical
• Short Circuit Protection of Inputs and Outputs
• Clamped Video Inputs
• 1 Switched Video Output 2 VPP
• Video Cross Talk : 50 dB Typical
• Short Circuit Protection of Inputs and Outputs
• Clamped Video Inputs
GL3820 Connection Diagram
GL3820
