GM1117

Features: ·Adjustable or Fixed Output·Output Current of 1.0A·Dropout Voltage (max.) 1.3V @ 1.0A·Line Regulation 0.2% max.·Load Regulation 0.4% max.·Fast Transient Response·Current Limit Protection·Thermal Shutdown ProtectionApplication·High Efficiency Linear Regulators·Post Regulators for Switchin...

product image

GM1117 Picture
See larger image
SeekIC No. : 004354050 Detail

GM1117: Features: ·Adjustable or Fixed Output·Output Current of 1.0A·Dropout Voltage (max.) 1.3V @ 1.0A·Line Regulation 0.2% max.·Load Regulation 0.4% max.·Fast Transient Response·Current Limit Protection·T...

GM1117 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
GM1117
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/23

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

·Adjustable or Fixed Output
·Output Current of 1.0A
·Dropout Voltage (max.) 1.3V @ 1.0A
·Line Regulation 0.2% max.
·Load Regulation 0.4% max.
·Fast Transient Response
·Current Limit Protection
·Thermal Shutdown Protection




Application

·High Efficiency Linear Regulators
·Post Regulators for Switching Supplies
·Microprocessor Supply
·Hard Drive Controllers
·Battery Chargers
·Adjustable Power Supply




Specifications

PARAMETER SYMBOL VALUE UNIT
Power Dissipation PD Internally limited W
Input Voltage VIN 7.0 V
Lead Temperature(Soldering, 10sec) TLEAD 300 °C
Operating Junction Temperature Range
Control Section
Power Transistor		 TJ 0 to 125
0 to 150		 °C
Storage Temperature Range TSTG -65 to + 150 °C
ESD Damage Threshold ESD 2.0 KV
Thermal Characteristics
SOT-223
Thermal Resistance, Junction-to-CaseDPAK
Thermal Resistance, Junction-to-Case2 D PAK
Thermal Resistance, Junction-to-Case		 RqJC 15
6.0
3.0		 °C/ W





Description

The GM1117 series of positive adjustable and fixed regulators are designed to provide 1.0A output with low dropout voltage performance. On-chip trimming adjusts the reference voltage to 1%. Put them to work in post regulators or microprocessor power supplies where low voltage operation and fast transient response are required. Pin-to-pin compatible with the LT1086 family of regulators,the GM1117's are available in surface-mount SOT-223 and TO-252 packages.
