Part Number: GM71CS18163CL
Description: The GM71C(S)18163C/CL is the new generation dynamic RAM organized 1,048,576 x 16 bi...
- Table of contents:
GM71CS18163CL
-
Suppliers
DataSheet
General Description
GM71CS18163CL General Description
The GM71C(S)18163C/CL is the new generation dynamic RAM organized 1,048,576 x 16 bit. GM71C(S)18163C/CL has realized higher density, higher performance and various functions by utilizing advanced CMOS process technology. The GM71C(S)18163C/CL offers Extended Data out(EDO) Mode as a high speed access mode. Multiplexed address inputs permit the GM71C(S)18163C/CL to be packaged in standard 400 mil 42pin plastic SOJ, and standard 400mil 44(50)pin plastic TSOP II. The package size provides high system bit densities and is compatible with widely available automated testing and insertion equipment.
GM71CS18163CL Maximum Ratings
| Symbol | Parameter | Rating | Unit |
| TA | Ambient Temperature under Bias | 0 ~ +70 | C |
| TSTG | Storage Temperature | -55 ~ +125 | C |
| VIN/OUT | Voltage on any Pin Relative to VSS | -1.0 ~ +7.0V | V |
| VCC | Supply voltage Relative to VSS | -1.0 ~ +7.0V | V |
| IOUT | Short Circuit Output Current | 50 | mA |
| PD | Power Dissipation | 1.0 | W |
GM71CS18163CL Features
·1,048,576 Words x 16 Bit Organization
· Extended Data Out Mode Capability
·Single Power Supply (5V+/-10%)
·Fast Access Time & Cycle Time
·Low Power
Active : 1045/935/825mW (MAX)
Standby : 11mW (CMOS level : MAX)
0.83mW (L-version : MAX)
·RAS Only Refresh, CAS beforeRASRefresh,
Hidden Refresh Capability
·All inputs and outputs TTL Compatible
·1024 Refresh Cycles/16ms
·1024 Refresh Cycles/128ms (L-version)
·Self Refresh Operation (L-version)
·Battery Back Up Operation (L-version)
·2 CAS byte Control
· Extended Data Out Mode Capability
·Single Power Supply (5V+/-10%)
·Fast Access Time & Cycle Time
·Low Power
Active : 1045/935/825mW (MAX)
Standby : 11mW (CMOS level : MAX)
0.83mW (L-version : MAX)
·RAS Only Refresh, CAS beforeRASRefresh,
Hidden Refresh Capability
·All inputs and outputs TTL Compatible
·1024 Refresh Cycles/16ms
·1024 Refresh Cycles/128ms (L-version)
·Self Refresh Operation (L-version)
·Battery Back Up Operation (L-version)
·2 CAS byte Control
GM71CS18163CL Connection Diagram
