Part Number: GPJ20M











Urgent Purchase

GPJ20M Maximum Ratings

CHARACTERISTICS
SYMBOL
GPJ20A
GPJ20B
GPJ20D
GPJ20G
GPJ20J
GPJ20K
GPJ20M
UNIT
Maximum Recurrent Peak Reverse Voltage
VRRM
50
100
200
400
600
800
1000
V
Maximum RMS Bridge input Voltage
VRMS
35
70
140
280
420
560
700
V
Maximum DC Blocking Voltage
VDC
50
100
200
400
600
800
1000
V
Maximum Average Forward Output Current @TC=100
IF(AV)
20
A
I2t Rating for fusing(t<8.3ms)
I2t
500
A2sec
Peak Forward Surge Current
Single single Sine-Wave
Superimposed on Rated Load (JEDEC Method)
IFSM
350
A
Maximum Instaneous Forward Voltage Drop perelement at 12.5A
VF
1.1
V
Maximum Reverse Leakage Currentat Rated @TA=25
DC Bolcking Voltage @TJ=100
IR
10
500
A
Typical Thermal Resistance perleg(Note1)
RJC
0.6
/W
Operating Junction and Storage Temperature Range
TJ,TSTG
-55 to +150
NOTES:
1. Device mounted on 220 x 220 x 1.6mm thick AL plate heatsink.

GPJ20M Features

• Diffused Junction
• Low Forward Voltage Drop
• High Current Capability
• High Reliability
• High Surge Current Capability
• Ideal for Printed Circuit Boards
• Pb free product are available : 99% Sn above can meet RoHS environment substance directive request
