GS-BT2416C2

Class :
Sensitivity :
Operating Supply Voltage :
Output Power :
Antenna Connector Type :
Maximum Operating Temperature :
Dimensions :
Frequency Band : 2.4 GHz
Data Rate : 721 Kbps
Interface Type : I2C, PCM, SPI, UART


Features:

Bluetooth specification V.1.2 compliant
Supports USB (1.1) /UART/PCM (Pulse Code
Modulation) interfaces
Bluetooth protocol layers support up to HCI
Output power class 2
Optimized link manager and control
Working distance up to 10 meters
Support wireless LAN coexistence
3.3V single supply voltage
CE Compliant
Safety EN60950-1 (2001)
EMC EN301 489 17V1.2.1


Application

Personal computers accessories
Laptop PCs and accessories
Hand held devices and accessories
Internet access points
Industrial controls


Specifications

Symbol	Parameter	Value		Unit
		Min	Max
VDD VIN	Supply voltage DC input voltage	Vss1-0.5	4 Vdd+0.3	V V
TSOLD Tstg	Soldering temperature Storage temperature	-40	240 +85

Description

SPG Bluetooth Class 2 Module is a highly  integrated module GS-BT2416C2 for fast implementation in  various applications to enable electronic devices  to communicate wirelessly with other Bluetooth enabled devices.

GS-BT2416C2 is a true saver for manufacturers to provide time-to-market products.

With different types of interface,  (USB/UART/PCM/SPI/I²C), the GS-BT2416C2 can be used in applications such as Notebook PCs and accessories, PDA, Access Points, Headphones and PC peripherals, etc.

Parameters:

Technical/Catalog Information	GS-BT2416C2
Vendor	STMicroelectronics
Category	RF and RFID
Frequency	2.4GHz
Data Rate - Maximum	721kbps
Modulation or Protocol	BlueTooth v1.2, Class 2
Applications	-
Power - Output	0dBm
Sensitivity	-74dBm
Voltage - Supply	3.3V
Current - Receiving	50mA
Current - Transmitting	90mA
Package / Case	Module
Operating Temperature	-20°C ~ 70°C
Data Interface	PCB, Surface Mount
Antenna Connector	PCB, Surface Mount
Packaging	Bulk
Memory Size	*
Drawing Number	*
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	GS BT2416C2 GSBT2416C2 497 5790 ND 4975790ND 497-5790
