Part Number: GTC220E









Description: The GTC220E provides the designer with the best combination of fast switching, ruggedized device desig...


Urgent Purchase

GTC220E General Description


The GTC220E provides the designer with the best combination of fast switching, ruggedized device design, ultra low on-resistance and cost-effectiveness.

GTC220E Maximum Ratings

Symbol Parameter Ratings Units
VDS Drain-Source Voltage 20 V
VGS Gate-Source Voltage ±12 V
ID @ Ta = 25 Continuous Drain Current3, VGS @ -10V 5.0 A
ID @ Ta = 70 Continuous Drain Current3, VGS @ -10V 4.0 A
IDM Pulsed Drain Current1,2 20 A
PD @ Ta = 25 Total Power Dissipation 1 W
  Linear Derating Factor 0.008 mW/
TJ, TSTG Junction and Storage Temperature Range -55 ~ +150

GTC220E Features

·Low on-resistance
·Capable of 2.5V gate drive
·Low drive current
·Surface mount package
