Part Number: H11L2X
Description: The H11L1, 2, 3, 4 series are optically coupled isolators consisting of a Gallium Arsenide infrared em...
- Table of contents:
H11L2X
-
Suppliers
DataSheet
General Description
H11L2X General Description
The H11L1, 2, 3, 4 series are optically coupled isolators consisting of a Gallium Arsenide infrared emitting diode and a Microprocessor Compatible Schmitt trigger output mounted in a standard 6 pin dual in line package.
H11L2X Maximum Ratings
Storage Temperature........-55°C to + 150°C
Operating Temperature ......-55°C to + 100°C
Lead Soldering Temperature
(1/16 inch (1.6mm) from case for 10 secs)....260°C
Operating Temperature ......-55°C to + 100°C
Lead Soldering Temperature
(1/16 inch (1.6mm) from case for 10 secs)....260°C
H11L2X Features
·Options :- 10mm lead spread - add G after part no. Surface mount - add SM after part no. Tape&reel - add SMT&R after part no.
·High data rate, 1MHz typical (NRZ)
·Microprocessor compatible drive
·Logic compatible output sinks 16 milliamperes at 0.4 volts maximum
·High Isolation Voltage (5.3kVRMS ,7.5kVPK )
·High common mode rejection ratio
·Fast swiching : t rise, t fall = 100ns typical
·Wide supply voltage capability, compatible with all popular logic systems
·Guaranteed On / Off threshold hysteresis
·High data rate, 1MHz typical (NRZ)
·Microprocessor compatible drive
·Logic compatible output sinks 16 milliamperes at 0.4 volts maximum
·High Isolation Voltage (5.3kVRMS ,7.5kVPK )
·High common mode rejection ratio
·Fast swiching : t rise, t fall = 100ns typical
·Wide supply voltage capability, compatible with all popular logic systems
·Guaranteed On / Off threshold hysteresis
H11L2X Typical Application
·Logic to logic isolator
·Line receiver-eliminates noise and transient problems
·Programmable current level sensor
·AC to TTl conversion - square wave shaping
·Digital programming of power supplies
·Interfaces computers with peripherals
·Line receiver-eliminates noise and transient problems
·Programmable current level sensor
·AC to TTl conversion - square wave shaping
·Digital programming of power supplies
·Interfaces computers with peripherals
