Features: • 128 bit memory array laser programmable• Bit duration : 32 periods of RF field• Bit coding according to ISO FDX-B• On chip resonnance capacitor• On chip supply buffer capacitor• Wide dynamic range• On chip voltage limiter• Full wave recti...
H4005: Features: • 128 bit memory array laser programmable• Bit duration : 32 periods of RF field• Bit coding according to ISO FDX-B• On chip resonnance capacitor• On chip sup...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Parameter |
Symbol |
Conditions |
Maximum AC peak Current induced on COIL1 and COIL2 Power Supply Storage temperature Electrostatic discharge maximum to MIL-STD-883C method 3015 |
ICOIL VDD Tstore VESD |
± 30 mA -0.3 to 7.5 V -55 to +200°C 1000 V |
Stresses above these listed maximum ratings may cause permanent damage to the device. Exposure beyond specified operating conditions may affect device reliability or cause malfunction.
The H4005 is a CMOS integrated circuit intented for use in electronic Read Only RF Transponders. The H4005 circuit is powered by an external coil placed in an electromagnetic field, and gets its master clock from the same field via one of the coil terminals. The other coil terminal is affected by the modulator. By turning on and off the modulation current, the chip will send back the 128 bits of information contained in a factory pre-programmed memory array.
The programming of the chip is performed by laser fusing of polysilicon links in order to store a unique code on each chip. Due to the low power consumption of the logic core, no supply buffer capacitor is required. Only an external coil is needed to obtain the chip function in H4005. A parallel resonance capacitor of 75 pF is also integrated.
