HA-5142_883

Voltage Between V+ and V- Terminals . . . . . . . . . . . . . . . . .. . 35V
Differential Input Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . 7V
Voltage at Either Input Terminal . . . . . . . . . . . . . . . V+ to VOutput
Current . . . . . . . . . . . . . . . . . . . . . . .. .Full Short Circuit Protection
Output Current Duration . . . . . . . . . . . . . . . . . . . . .  . . . Indefinite
One Amplifier Shorted to Ground
Junction Temperature (T_J) . . . . . . . . . . . . . . . . .  . . . . . . . . +175
Storage Temperature Range . . . . . . . . . . . . . . . . . -65 to +150
ESD Rating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . <2000V
Lead Temperature (Soldering 10s). . . . . . . . . . . . . . . . . . . . +300
CAUTION: Stresses above those listed in "Absolute Maximum Ratings" may cause permanent damage to the device. This is a stress only rating and operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied.

The HA-5142/883 dual, ultra-low power operational amplifier provides AC and DC performance characteristics similar to, or better than most general purpose amplifiers while only drawing 1/30 of the supply current of most general purpose amplifiers. This amplifier is well suited to applications which require low power dissipation and good electrical characteristics.

The HA-5142/883 provides accurate signal processing by virtue of their low input offset voltage (6mV), low input bias current (100nA), high open loop gain (20kV/V) and low noise (20nV/Hz). These characteristics coupled with a 1.5V/s slew rate and a 24kHz bandwidth make the HA-5142/883 ideal for use in low power instrumentation, audio amplifier and active filter designs.
