HC139

DescriptionThe 'HC139 is a high-speed cmos logic dual 2- to 4-line decoder/demultiplexer.It devices contain two independent binary to one of four decoders each with a single active low enable input (1E or 2E). Data on the select inputs (1A0 and 1A1 or 2A0 and 2A1) cause one of the four normally hi...

product image

HC139 Picture
See larger image
SeekIC No. : 004359150 Detail

HC139: DescriptionThe 'HC139 is a high-speed cmos logic dual 2- to 4-line decoder/demultiplexer.It devices contain two independent binary to one of four decoders each with a single active low enable input ...

HC139 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
HC139
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Description

The 'HC139 is a high-speed cmos logic dual 2- to 4-line decoder/demultiplexer.It devices contain two independent binary to one of four decoders each with a single active low enable input (1E or 2E). Data on the select inputs (1A0 and 1A1 or 2A0 and 2A1) cause one of the four normally high outputs to go low and is functionally the same as the CD4556B and is pin compatible with it.

Features of the 'HC139 are::(1)multifunction capability;(2)binary to 1 of 4 decoders or 1 to 4 line demultiplexer;(3)active low mutually exclusive outputs;(4)Fanout (Over Temperature Range):Standard Outputs is 10 LSTTL Loads,Bus Driver Outputs is 15 LSTTL Loads;(5) wide operating temperature range:-55 to 125;(6)balanced propagation delay and transition times;(7)significant power reduction compared to LSTTL Logic ICs;(8)operation:2V to 6V;(9)high noise immunity: NIL = 30%, NIH = 30%of VCC at VCC = 5V


The absolute maximum ratings of the 'HC139 can be summarized as:(1)dc supply voltage, VCC:-0.5V to 7V;(2) dc input diode current, IIK:for VI < -0.5V or VI > VCC + 0.5V is ±20mA;(3)dc output diode current, IOK:for VO < -0.5V or VO > VCC + 0.5V is ±20mA;(4)dc output source or sink current per output pin, IO:For VO > -0.5V or VO < VCC + 0.5V is ±25mA;(6)dc vcc or ground current, ICC or IGND:±50mA.

If you want to know more information such as the electrical characteristics about the 'HC139, please download the datasheet in www.seekic.com or www.chinaicmart.com .
