Part Number: HCP20C60











Urgent Purchase

HCP20C60 Maximum Ratings
IDRM
10
200
uA
 VAK=VDRM VRRM,
Tc=25
Tc=125
VTM
 (1)
1.6
V
 ITM=24A,tp=380us
IGT
 (2)
15
mA
 VAK =6V(DC), RL=10 ohm
Tc=25
VGT
 (2)
1.5
V
 VAK =6V(DC), RL=10 ohm
Tc=25
VGD
 (1)
0.2

V
 VAK =12V, RL=100 ohm
Tc=125
IH
20
mA
 IT=100mA,
Tc=25
(dv/dt)c
200

V/us
 VD=VDRM 67%, ,Tj=125
Rth(j-c)

1.1
/W
Rth(j-a)
60
/W

HCP20C60 Typical Application

, ,,,.
