General Description
HFBR-5104T General Description
The HFBR-5100 family of transceivers from Hewlett-Packard provide the system designer with products to implement a range of FDDI and ATM (Asynchronous Transfer Mode) designs at the 100 Mbps/125 MBd rate.
The transceivers are all supplied in the new industry standard 1x9 SIP package style with either a duplex SC or a duplex ST* connector interface.
HFBR-5104T Maximum Ratings
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Reference |
| Storage Temperature | TS | -40 | 100 | °C | ||
| Lead Soldering Temperature | TSOLD | 260 | °C | |||
| Lead Soldering Time | tSOLD | 10 | sec. | |||
| Supply Voltage | VCC | -0.5 | 7.0 | V | ||
| Data Input Voltage | VI | -0.5 | VCC | V | ||
| Differential Input Voltage | VD | 1.4 | V | Note 1 | ||
| Output Current | IO | 50 | mA |
HFBR-5104T Features
• Full Compliance with the Optical Performance Requirements of the FDDI PMD Standard
• Full Compliance with the FDDI LCF-PMD Standard
• Full Compliance with the Optical Performance Requirements of the ATM 100 Mbps Physical Layer
• Full Compliance with the Optical Performance Requirements of 100 Base-FX Version of IEEE 802.3u
• Very Low Cost 800 nm Alternative with FDDI and ATM Compliant Signaling
• Multisourced 1x9 Package Style with Choice of Duplex SC or Duplex ST* Receptacle
• Wave Solder and Aqueous Wash Process Compatible
• Manufactured in an ISO 9002 Certified Facility
• Full Compliance with the FDDI LCF-PMD Standard
• Full Compliance with the Optical Performance Requirements of the ATM 100 Mbps Physical Layer
• Full Compliance with the Optical Performance Requirements of 100 Base-FX Version of IEEE 802.3u
• Very Low Cost 800 nm Alternative with FDDI and ATM Compliant Signaling
• Multisourced 1x9 Package Style with Choice of Duplex SC or Duplex ST* Receptacle
• Wave Solder and Aqueous Wash Process Compatible
• Manufactured in an ISO 9002 Certified Facility
HFBR-5104T Typical Application
• Multimode Fiber Backbone Links
• Multimode Fiber Wiring Closet to Desktop Links
• Very Low Cost Multimode Fiber 800 nm Links from Wiring Closet to Desktop
• Multimode Fiber Wiring Closet to Desktop Links
• Very Low Cost Multimode Fiber 800 nm Links from Wiring Closet to Desktop
HFBR-5104T Connection Diagram
HFBR-5104T
PDF/DataSheet Download
- Datasheet: HFBR-5104T
- File Size: 346821 KB
- Manufacturer: HP [Agilent(Hewlett-Packard)]
- Click here to Download
