HFE4225

The HFE4225 is designed as one kind of next generation high power LEDs with plastic ST package. It can be used in IEEE 802.3 Ethernet and IEEE 802.5J Token Ring applications such as repeaters, bridges, hubs, routers, switches and gateways. Features of the HFE4225 are:(1)wave solderable;(2)fiber dip package style;(3)850 nm GaAIAs LED;(4)straight plastic barrel and housing;(5)industry standard ST fiber connector;(6)high reliability construction.

The absolute maximum ratings of the HFE4225 can be summarized as:(1)storage temperature:-55 to +85;(2)case operating temperature:-40 to +85;(3)lead solder temperature:269, 10 s;(4)reverse voltage:1.8 V;(5)continuous forward current:100 mA. If you want to know more information such as the electrical characteristics about the HFE4225, please download the datasheet in www.seekic.com or www.chinaicmart.com .
