General Description
HLMP-3651 General Description
The 5 volt and 12 volt series lamps contain an integral current limiting resistor in series with the LED. This allows the lamp to be driven from a 5 volt/12 volt source without an external current limiter. The red LEDs are made from GaAsP on a GaAs substrate. The High Efficiency Red and Yellow devices use GaAsP on a GaP substrate.
The green devices use GaP on a GaP substrate. The diffused lamps provide a wide off-axis viewing angle.
HLMP-3651 Maximum Ratings
| Red/HER/Yellow 5 Volt Lamps | Red/HER/Yellow 12 Volt Lamps | Green 5 Volt Lamps | Green 12 Volt Lamps | |
| DC Forward Voltage (TA = 25°C) | 7.5 Volts[2] | 15 Volts[3] | 7.5 Volts[2] | 15 Volts[3] |
| Reverse Voltage (IR = 100 A) | 5 Volts | 5 Volts | 5 Volts | 5 Volts |
| Operating Temperature Range | -40°C to 85°C | -40°C to 85°C | -20°C to 85°C | -20°C to 85°C |
| Storage Temperature Range | -55°C to 100°C | -55°C to 100°C | -55°C to 100°C | -55°C to 100°C |
| Lead Soldering Temperature | 260°C for 5 seconds | |||
2. Derate from TA = 50°C at 0.071 V/°C, see Figure 3.
3. Derate from TA = 50°C at 0.086 V/°C, see Figure 4.
HLMP-3651 Features
• Integral Current Limiting Resistor
• TTL Compatible
Requires no External Current Limiter with 5 Volt/12 Volt Supply
• Cost Effective
Saves Space and Resistor Cost
• Wide Viewing Angle
• Available in All Colors
Red, High Efficiency Red, Yellow, and High Performance Green in T-1 and T-13/4 Packages
• TTL Compatible
Requires no External Current Limiter with 5 Volt/12 Volt Supply
• Cost Effective
Saves Space and Resistor Cost
• Wide Viewing Angle
• Available in All Colors
Red, High Efficiency Red, Yellow, and High Performance Green in T-1 and T-13/4 Packages
