HR300

Features: • 40°to +85°C operation• 18 to 36 VDC input (19 to 36 VDC input HR301-2805)• Fully Isolated• Optocoupler feedback• Fixed frequency, 240 to 300 kHz typical• Topology Push-Pull Forward• 50 V for up to 50 ms transient protection• Inhibit func...

product image

HR300 Picture
See larger image
SeekIC No. : 004365505 Detail

HR300: Features: • 40°to +85°C operation• 18 to 36 VDC input (19 to 36 VDC input HR301-2805)• Fully Isolated• Optocoupler feedback• Fixed frequency, 240 to 300 kHz typicalR...

HR300 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
HR300
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/27

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• 40°to +85°C operation
• 18 to 36 VDC input (19 to 36 VDC input HR301-2805)
• Fully Isolated
• Optocoupler feedback
• Fixed frequency, 240 to 300 kHz typical
• Topology Push-Pull Forward
• 50 V for up to 50 ms transient protection
• Inhibit function
• Indefinite short circuit protection
• Remote sense on HR301-2805 model
• Up to 86% efficiency


Specifications

Input Voltage
• 18 to 36 VDC (19 to 36 VDC HR301-2805)
Output Power
• 30 watts
Lead Soldering Temperature (10 sec per lead)
• 300°C
Storage Temperature Range (Case)
• 55°C to +125°C


Description

HR300 Series™ DC/DC converters combine the small size and high reliability of hybrid-based components, the high efficiency of switching regulators, and the isolation, regulation, and low noise characteristics of linear regulators.
