HV14

      The HV14 series(14 pin DIL High Frequency HCMOS Clock Oscillator) are supplied voltage  2.5V or 3.3Volts with a high frequency range at low cost, which are designed to provide a high quality HCMOS output at high frequencies from 125MHz to 200MHz. Phase and RMS period jitter are kept within low limits. An enable/disable function is standard and the oscillator may also be specified with a power down function. and the HV14 series are also under the industry-standard 14 pin DIL package, frequency Range 125MHz to 200MHz, tristate function option to conserve power.
      Some parameters of the HV14 series are got, frequency Range(125.0MHz to 200.0MHz), Output Logic(HCMOS), Phase Jitter(3.5ps typical), RMS Period Jitter(4.0ps typical), Frequency Stability(Commercial: ±25ppm to ±100ppm -10° to +70°C; Industrial: ±25ppm to ±100ppm -40° to +85°C; Input Voltage: +2.5V to +3.3VDC ±10%), Output Voltage(High '1':  +2.97V minimum; Low '0':  +0.33 V maximum; Rise/Fall Time:  0.25ns typical, 0.5ns max.(20%Vdd to 80%Vdd)), Current Consumption(80mA typical (Frequency dependent)), Load(15pF), Start-up Time(5ms typical, 10ms maximum), Duty Cycle(50% ±5% (Measured at Vdd-1.3V)), Input Static(Discharge Protection:  2kV maximum; Ageing:  ±2pmm per year maximum).
      Then the HV14 series' supply Voltage(+4.6 VDC max), Input Voltage Vi(Vss-0.5 min., Vdd +0.5V max), Input Voltage Vo(Vss-0.5 min., Vdd +0.5V max) are also got.
