HVR320
-
Suppliers
DataSheet
General Description
HVR320 Maximum Ratings
RATING |
SYMBOL |
HVR312 |
HVR314 |
HVR316 |
HVR318 |
HVR320 |
UNIT |
| Maximum Repetitive Peak Reverse Voltage | VRRM |
1200 |
1400 |
1600 |
1800 |
2000 |
Volts |
| Maximum RMS Voltage | VRMS |
840 |
980 |
1120 |
1260 |
1400 |
Volts |
| Maximum DC Blocking Voltage | VDC |
1200 |
1400 |
1600 |
1800 |
2000 |
Volts |
| Maximum Average Forward Current Ta = 75°C | IF(AV) |
3.0 |
Amp. |
||||
| Peak Forward Surge Current 8.3ms Single half sine wave Superimposed on rated load (JEDEC Method) |
IFSM |
100 |
Amps. |
||||
| Maximum Peak Forward Voltage at IF = 1.0 Amp. | VF |
2.0 |
Volts |
||||
| Maximum DC Reverse Current Ta = 25°C at Rated DC Blocking Voltage Ta = 100°C |
IR |
10 |
A |
||||
| Typical Junction Capacitance (Note 1) | Cj |
36 |
pF |
||||
| Typical Thermal Resistance (Note 2) | RJA |
26 |
/W |
||||
| Junction Temperature Range | TJ |
- 40 to + 150 |
|||||
| Storage Temperature Range | TSTG |
- 40 to + 150 |
|||||
HVR320 Features
* High current capability
* High surge current capability
* High reliability
* Low reverse current
* Low forward voltage drop
* High surge current capability
* High reliability
* Low reverse current
* Low forward voltage drop
