ICS8520

Supply Voltage, VCCx................... 4.6V
Inputs, V_I ................. -0.5V to VCC+0.5 V
Outputs, V_O ................ -0.5V to VCC+0.5V
Package Thermal Impedance, _JA .... 46/W (no air flow)
Storage Temperature, T_STG .......... -65 to 150

Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These ratings are stress specifications only. Functional operation of product at these conditions or any conditions beyond those listed in the DC Characteristics or AC Characteristics is not implied. Exposure to absolute maximum rating conditions for extended periods may affect product reliability.

The ICS8520 is a low skew, high performance 1-to-16 Differential-to-3.3V LVHSTL Fanout Buffer and a member of the HiPerClockS™ family of High Performance Clock Solutions from ICS. The ICS8520 has 1 clock input pair. The CLK, nCLK pair can accept most standard differential input levels.

Guaranteed output skew, part-to-part skew and crossover voltage characteristics make the ICS8520 ideal for interfacing to today's most advanced microprocessor and static RAMs.
