ICS85310I-01

Supply Voltage, V_{CC...................................................} 4.6V
Inputs, V_I ...........................................-0.5V to V_CC + 0.5V
Outputs, I_O
  Continuous Current ................................................50mA
  Surge Curren........................................................ 100mA
Package Thermal Impedance, _JA ........47.9°C/W (0 lfpm)
Storage Temperature, T_{STG....................} -65°C to 150°C

NOTE: Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These ratings are stress specifications only. Functional operation of product at these conditions or any conditions beyond those listed in the DC Characteristics or AC Characteristics is not implied. Exposure to absolute maximum rating conditions for extended periods may affect product reliability.

The ICS85310I-01 is a low skew, high performance 1-to-10 Differential-to-2.5V/3.3V ECL/ LVPECL Fanout Buffer and a member of the HiPerClockS™ family of High Performance Clock Solutions from ICS. The CLKx, nCLKx pairs can accept most standard differential input levels. The ICS85310I-01 is characterized to operate from either a 2.5V or a 3.3V power supply. Guaranteed output and partto- part skew characteristics make the ICS85310I-01 ideal for those clock distribution applications demanding well defined performance and repeatability.
