ICS8535-01

•4 differential 3.3V LVPECL outputs
•Selectable CLK0 or CLK1 inputs for redundant and multiple frequency fanout applications
•CLK0 or CLK1 can accept the following differential input levels:  LVCMOS or LVTTL
•Maximum output frequency up to 266MHz
•Translates LVCMOS and LVTTL levels to 3.3VLVPECL levels
•Output skew:  30ps (maximum)
•Part-to-part skew:  150ps (maximum)
•Propagation delay:  1.9ns (maximum)
•3.3V operating supply
•0°C to 70°C ambient operating temperature
•Industrial temperature information available upon request

The ICS8535-01 is a low skew, high performance1-to-4 LVCMOS-to-3.3V LVPECL fanout bufferand a member of the HiPerClockS™ family of High Performance Clock Solutions from ICS. TheICS8535-01 has two single ended clock inputs.the single ended clock input accepts LVCMOS or LVTTL in- put levels and translate them to 3.3V LVPECL levels. Theclock enable is internally synchronized to eliminate runt clock pulses on the output during asynchronous assertion/ deassertion of the clock enable pin. Guaranteed output and part-to-part skew characteristics make the ICS8535-01 ideal for those applications demand-ing well defined performance and repeatability.
