ID1A-6S-2.54SF

1. Suited for Plug-in SIM Cards of the GSM Standard (11.11)
In Europe, SIM card Subscriber Identity Modules are used
for subscriber identification with portable telephone terminals of the GSM system for which standards have been unified. The ID1A Series of sockets are suited for use with GSM standard (11.11) plug-in SIM cards.
2. Miniature and Thin
These sockets are miniature and thin with a height of 2.45mm, length of 30.6 mm, and width of 17.4 mm. The weight has been reduced by 30% compared with our existing products. (See Photograph (1).)
3. Suited to Automatic Mounting
The board mounting method is of the surface mount type.In addition to the standard tray packaging specification, an embossed tape specification suited to automatic mounting is also available.
4. Prevention of Incorrect Insertion to the Board A board-positioning boss prevents incorrect insertion to the board by means of boss position and boss diameter.
5. Slide Lock System
An original lock structure securely holds the SIM card and easy opening and closing of the card holder is another feature. (See Photograph (2).)
