Purchase IDB09E60, In-stock IDB09E60 From SeekIC.
MFG:moseft Package Cooled:INFINEON D/C:07+
- Table of contents:
IDB09E60
-
Suppliers
DataSheet
General Description
IDB09E60 Maximum Ratings
| Parameter | Symbol | Value | Unit |
| Repetitive peak reverse voltage | VRRM | 600 | V |
| Continous forward current TC=25°C TC=90°C |
IF | 19.3 13 |
A |
| Surge non repetitive forward current TC=25°C, tp=10 ms, sine halfwave |
IFSM | 40 | |
| Maximum repetitive forward current TC=25°C, tp limited by Tjmax, D=0.5 |
IFRM | 29.5 | |
| Power dissipation TC=25°C TC=90°C |
Ptot | 57.7 32.7 |
W |
| Operating and storage temperature | Tj , Tstg | -55...+175 | °C |
| Soldering temperature 1.6mm(0.063 in.) from case for 10s |
TS | 255 | °C |
IDB09E60 Features
• 600 V EmCon technology
• Fast recovery
• Soft switching
• Low reverse recovery charge
• Low forward voltage
• 175°C operating temperature
• Easy paralleling
• Fast recovery
• Soft switching
• Low reverse recovery charge
• Low forward voltage
• 175°C operating temperature
• Easy paralleling
IDB09E60
PDF/DataSheet Download
- Datasheet: IDB09E60
- File Size: 202946 KB
- Manufacturer: INFINEON [Infineon Technologies AG]
- Click here to Download
