Purchase IMD9A, In-stock IMD9A From SeekIC.
MFG:Rohm Package Cooled:Sot-163 D/C:09+
- Table of contents:
IMD9A
-
Suppliers
DataSheet
General Description
IMD9A Maximum Ratings
Paramete |
Symbo |
Limits |
Unit |
|
| Supply voltage | VCC |
50 |
V |
|
| Input voltage | VIN |
−6 to +40 |
V |
|
| Output current | IO |
70 |
mA |
|
| Collector current | IC (Max.) |
100 |
mA |
|
| Power dissipation | EMD9, UMD9N | Pd | 150(TOTAL) |
mW *1 |
| IMD9A | 300(TOTAL) |
mW *2 |
||
| Junction temperature | Tj |
150 |
||
| Storage temperature | TSTG |
-55~+150 |
||
IMD9A Features
DTA114Y and DTC114Y transistors are built-in a EMT or UMT or SMT package.
IMD9A
PDF/DataSheet Download
- Datasheet: IMD9A
- File Size: 85968 KB
- Manufacturer: ROHM [Rohm]
- Click here to Download
