Features: • Wide Input Voltage Range 2.5V to 21V• Wide Output Voltage Range 0.6V to 12V• Continuous 12A Load Capability• 600kHz High Frequency Operation• Programmable Over-Current Protection• Programmable PGood Output• Hiccup Current Limit• Precision...
IR3820: Features: • Wide Input Voltage Range 2.5V to 21V• Wide Output Voltage Range 0.6V to 12V• Continuous 12A Load Capability• 600kHz High Frequency Operation• Programmable O...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
The IR3820 SupIRBuckTM is an easy-to-use, fully integrated and highly efficient DC/DC regulator. The onboard switching controller and MOSFETs make the IR3820 a space-efficient solution, providing accurate power delivery for low output voltage applications.
The IR3820 operates from a 4.5V to 14V input supply and generates an output voltage adjustable from 0.6V to 0.75*Vin at loads up to 12A. A versatile regulator offering programmability of startup time, power good threshold and current limit, the IR3820's fixed 600kHz switching frequency allows the use of small external components.
The IR3820 also features important protection functions, such as Pre-Bias startup, hiccup current limit and thermal shutdown to provide the required system level security in the event of fault conditions.
