IRFP4368PBF

MOSFET MOSFT 75V 350A 1.85mOhm 380nC Qg

product image

IRFP4368PBF Picture
See larger image
SeekIC No. : 00150096 Detail

IRFP4368PBF: MOSFET MOSFT 75V 350A 1.85mOhm 380nC Qg

IRFP4368PBF Data Sheet

floor Price/Ceiling Price

US $ 2.6~4.67 / Piece | Get Latest Price
Part Number:
IRFP4368PBF
Mfg:
International Rectifier
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • Unit Price
  • $4.67
  • $3.41
  • $2.7
  • $2.6
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/5

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Transistor Polarity : N-Channel Drain-Source Breakdown Voltage : 75 V
Gate-Source Breakdown Voltage : 20 V Continuous Drain Current : 350 A
Mounting Style : Through Hole Package / Case : TO-247AC
Packaging : Tube

Description

Resistance Drain-Source RDS (on) :
Configuration :
Maximum Operating Temperature :
Transistor Polarity : N-Channel
Mounting Style : Through Hole
Packaging : Tube
Drain-Source Breakdown Voltage : 75 V
Gate-Source Breakdown Voltage : 20 V
Package / Case : TO-247AC
Continuous Drain Current : 350 A


Application

·High Efficiency Synchronous Rectification in SMPS
·Uninterruptible Power Supply
·High Speed Power Switching
·Hard Switched and High Frequency Circuits


Specifications

  Parameter Max. Units
ID @ TC = 25 Continuous Drain Current, VGS @ 10V(Silicon Limited) 350 A
ID @ TC = 100 Continuous Drain Current, VGS @ 10V(Silicon Limited) 250
ID @ TC = 25 Continuous Drain Current, VGS @ 10V (Wire Bond Limited) 195
IDM Pulsed Drain Current 1280
PD @ TC = 25 Max. Power Dissipation 520 W
  Linear Derating Factor 3.4 W/
VGS Gate-to-Source Voltage ±20 V
dv/dt Peak Diode Recovery dv/dt 5.0 V/ns
TJ, TSTG Junction and Storage Temperature Range -55 to 175
  Soldering Temperature, for 10 seconds
(1.6mm from case)		 300
  Mounting torque, 6-32 or M3 screw 10 lb`in (1.1N`m)



Parameters:

Technical/Catalog InformationIRFP4368PBF
VendorInternational Rectifier
CategoryDiscrete Semiconductor Products
Mounting TypeThrough Hole
FET PolarityN-Channel
Drain to Source Voltage (Vdss)75V
Current - Continuous Drain (Id) @ 25° C195A
Rds On (Max) @ Id, Vgs1.85 mOhm @ 195A, 10V
Input Capacitance (Ciss) @ Vds 19230pF @ 50V
Power - Max520W
PackagingTube
Gate Charge (Qg) @ Vgs570nC @ 10V
Package / CaseTO-247AC
FET FeatureLogic Level Gate
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names IRFP4368PBF
IRFP4368PBF
