Purchase IRS26310DJPBF, In-stock IRS26310DJPBF From SeekIC.

MFG:International Rectifier  Category:Integrated Circuits (ICs)

IRS26310DJPBF Product Image

IRS Series Datasheet download

Five Points

Part Number: IRS26310DJPBF

Category: Integrated Circuits (ICs)

MFG: International Rectifier





Descriptions: IC DRIVER BRIDGE 3-PHASE 44-PLCC

Price Break

108

Unit Price

4.00500

Extended Price

432.54

(All prices are in USD) Prices for reference only
Urgent Purchase

IRS26310DJPBF General Description

IC DRIVER BRIDGE 3-PHASE 44-PLCC

IRS26310DJPBF Parameters

Technical/Catalog InformationIRS26310DJPBF
VendorInternational Rectifier
CategoryIntegrated Circuits (ICs)
Configuration3 Phase Bridge
Voltage - Supply12 V ~ 20 V
Current - Peak200mA
Delay Time530ns
Package / Case44-PLCC (32 Leads)
PackagingTube
Number of Outputs3
Input TypeNon-Inverting
Number of Configurations1
Operating Temperature-40°C ~ 125°C
High Side Voltage - Max (Bootstrap)600V
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names IRS26310DJPBF
