Part Number: IS62LV1288LL
Description: The ISSI IS62LV1288LL is a low power and low Vcc,131,072-word by 8-bit CMOS static RAM. It is fabricat...
- Table of contents:
IS62LV1288LL
-
Suppliers
DataSheet
General Description
IS62LV1288LL General Description
The ISSI IS62LV1288LL is a low power and low Vcc,131,072-word by 8-bit CMOS static RAM. It is fabricated using ISSI's high-performance CMOS technology. This highly reliable process coupled with innovative circuit design techniques, yields higher performance and low power consumption devices.
When CE1 is HIGH or CE2 is LOW (deselected), the device assumes a standby mode at which the power dissipation can be reduced by using CMOS input levels. Easy memory expansion is provided by using two Chip Enable inputs, CE1 and CE2. The active LOW Write Enable (WE) controls both writing and reading of the memory.
The IS62LV1288LL is available in 32-pin TSOP (Type I), STSOP (8 x 13.4mm), and 450-mil plastic SOP (525-mil pin to pin) packages.
IS62LV1288LL Maximum Ratings
| Symbol | Parameter | Value | Unit |
| VTERM VCC TBIAS TSTG PT |
Terminal Voltage with Respect to GND Vcc related to GND Temperature Under Bias Storage Temperature Power Dissipation |
0.5 to Vcc + 0.5 0.3 to +3.6 40 to +85 65 to +150 0.7 |
V V W |
Notes:
1. Stress greater than those listed under ABSOLUTE MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.
IS62LV1288LL Features
• Access times of 45, 55, and 70 ns
• Low active power: 60 mW (typical)
• Low standby power: 15 µW (typical) CMOS standby
• Low data retention voltage: 2V (min.)
• Ultra Low Power
• Output Enable (OE) and two Chip Enable (CE1 and CE2) inputs for ease in applications
• TTL compatible inputs and outputs
• Single 2.5V (min.) to 3.45V (max.) power supply
• Industrial temperature available
• Available in 32-pin TSOP (Type I), 32-pin STSOP, and 450-mil SOP
• Low active power: 60 mW (typical)
• Low standby power: 15 µW (typical) CMOS standby
• Low data retention voltage: 2V (min.)
• Ultra Low Power
• Output Enable (OE) and two Chip Enable (CE1 and CE2) inputs for ease in applications
• TTL compatible inputs and outputs
• Single 2.5V (min.) to 3.45V (max.) power supply
• Industrial temperature available
• Available in 32-pin TSOP (Type I), 32-pin STSOP, and 450-mil SOP
IS62LV1288LL Connection Diagram
