Features: • Single-chip voice record/playback solution• Single +3 volt supply• Low-power consumption Operating current: ICC Play = 15 mA (typical)ICC Rec = 25 mA (typical) Standby current: 1 A (typical)• Single-chip durations of 8, 10, 12, and 16 minutes• High-quali...
ISD4004: Features: • Single-chip voice record/playback solution• Single +3 volt supply• Low-power consumption Operating current: ICC Play = 15 mA (typical)ICC Rec = 25 mA (typical) Standb...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
CONDITIONS | VALUES |
Junction temperature | 150 |
Storage temperature range | -65 to +150 |
Voltage applied to any pin | (VSS 0.3V) to (VCC +0.3V) |
Voltage applied to MOSI, SCLK, INT, RAC and SS pins (input current limited to ± 20mA | (VSS 1.0 V) to 5.5V |
Lead temperature (Soldering 10sec) | 300 |
VCC VSS | -0.3V to +7.0V |
The ISD4004 ChipCorder® Products provide highquality, 3-volt, single-chip record/playback solutions for 8- to 16-minute messaging applications which are ideal for cellular phones and other portable products. The CMOS-based devices include an on-chip oscillator, antialiasing filter, smoothing filter, AutoMute™ feature, audio amplifier, and high density, multilevel Flash storage array. The ISD4004 series is designed to be used in a microprocessor- or microcontroller-based system. Address and control are accomplished through a Serial Peripheral Interface (SPI) or Microwire Serial Interface to minimize pin count.
Recordings are stored in on-chip nonvolatile memory cells, providing zero-power message storage. This unique, single-chip solution is made possible through ISD's patented multilevel storage technology. Voice and audio signals are stored directly into memory in their natural form, providing high-quality, solid-state voice reproduction.
