Part Number: IT1A-252S-SV
Description: High-speed matched-impedance parallel board-to-board connector designed for applications requiring boa...
- Table of contents:
IT1A-252S-SV
-
Suppliers
DataSheet
General Description
IT1A-252S-SV General Description
High-speed matched-impedance parallel board-to-board connector designed for applications requiring board-toboard spacing with transmission speeds exceeding 1GHz. The connection system has matched impedance of 50 ohm or can be customized. Contacts are on 0.5mm pitch.
IT1A-252S-SV Features
` Impedance Matching using a 4-Layer Board
The innovative transmission module uses PC boards with a strip line design of transmission lines, providing matched impedance of 50 ohms, for standard product.
` Supports Multiple Connectors per board
Designed with a tolerance of +/- 0.2mm for both the X and Y-axis. The three-piece structure and the +/- 0.2mm tolerance allows 3 or more IT1's to be mounted on a single board.
` Customized Board-to-Board Distance
Board-to-board distance can be customized, from 16mm to 40mm.
Ground lines or additional traces can be added to support high level, high speed transmission or mixed power/signal applications.
` Signal to Ground Ratio
The standard signal-to-ground ratio is 10:2, which makes reliable matching of the characteristic impedance of each transmission line. This ratio also can be customized.
` Contact Reliability
Use of double contact points on each of the contacts assures highly reliable performance
The innovative transmission module uses PC boards with a strip line design of transmission lines, providing matched impedance of 50 ohms, for standard product.
` Supports Multiple Connectors per board
Designed with a tolerance of +/- 0.2mm for both the X and Y-axis. The three-piece structure and the +/- 0.2mm tolerance allows 3 or more IT1's to be mounted on a single board.
` Customized Board-to-Board Distance
Board-to-board distance can be customized, from 16mm to 40mm.
Ground lines or additional traces can be added to support high level, high speed transmission or mixed power/signal applications.
` Signal to Ground Ratio
The standard signal-to-ground ratio is 10:2, which makes reliable matching of the characteristic impedance of each transmission line. This ratio also can be customized.
` Contact Reliability
Use of double contact points on each of the contacts assures highly reliable performance
IT1A-252S-SV Typical Application
· Routers, servers, base stations and other telecommunication equipment.
