The JT6J15A-AS is a 80-channel-output row driver for a STN dot matrix LCD.The JT6J15A-AS features 28V LCD drive voltage. The JT6J15A-AS is able to drive LCD panels with a duty ratio of up to 1/160.As the JT6J15A-AS is equipped with a built-in voltage divider resistor, power supply operation amplifier, four and six-fold booster circuit, a contrast control circuit and a booster oscillator(oscillating capacitance is built in, and oscillating resistance is attached externally,) it is easy to structure a low power consumption LCD system by combining it with the JT6J14-AS column driver.
The JT6J15A-AS has the following features include:(1)display duty application:to 1/160;(2)LCD drive signal:80;(3)display-off function:when/DSPOF is "L", all LCD drive outputs (01 to 080) remain at the VSS/V5 level;(4)LCD drive voltage:11 to 28 V (maximum drive voltage=30 V);(5)power supply voltage:2.7 to 5.5 V.This is especially true for devices in which the surface (back), or side of the chip is exposed. When designing circuits,make sure that devices are protected against incident light from external sources. Exposure to light both during regular operation and during inspection must be taken into account.
The absolute maximum ratings of the JT6J15A-AS are:(1)power supply voltage:-0.3 to 6.0V;(2)storage temperature range:-40 to +125;(3)operating temperature range:-20 to +75;(4)input voltage:-0.3 to Vdd+0.3V;(5)power supply voltage:Vdd to 30.0V.TOSHIBA is continually working to improve the quality and the reliability of its products.Nevertheless, semiconductor devices in general can malfunction or fail due to their inherent electrical sensitivity and vulnerability to physical stress.It is the responsibility of the buyer, when utilizing TOSHIBA products, to observe standards of safety, and to avoid situations in which a malfunction or failure of a TOSHIBA product could cause loss of human life, bodily injury or damage to property.In developing your designs, please ensure that TOSHIBA products are used within specified operating ranges as set forth in the most recent products specifications. Also, please keep in mind the precautions and conditions set forth in the TOSHIBA Semiconductor Reliability Handbook.
