Part Number: KA3082N
Description: The FAN8082 is a monolithic integrated circuit designed for driving bi-directional DC motor with braki...
- Table of contents:
KA3082N
-
Suppliers
DataSheet
General Description
KA3082N General Description
The FAN8082 is a monolithic integrated circuit designed for driving bi-directional DC motor with braking and speed con-trol, and it is suitable for the loading motor driver of VCR, CDP, and TOY systems. The speed control can be achieved by adjusting the external voltage of the speed control pin.It has two pins of logic inputs for controlling the forward/ reverse and braking.
KA3082N Maximum Ratings
| Type Number | Symbo | Value | Units | Remark |
| Supply voltage | VCCmax | 18 | V | - |
| Maxium Output current | IOmax | 1.6note1 | A | - |
| Power dissipation | Pd | 1.0note2 | W | - |
| Operating temperature | TOPR | −25 ~ +75 | °C | |
| Storage temperature | TSTG | −55 ~ +125 | °C | - |
KA3082N Features
• Built-in brake function for stable brake characteristics.
• Built-in element to absorb a surge current derived from changing motor direction and braking motor drive.
• Motor speed control by an external voltage.
• Stable motor direction change.
• Interfaces with CMOS devices.
• Built-in the thermal shut down circuit (165°C).
• Low standby current. (6.5mA)
• Built-in element to absorb a surge current derived from changing motor direction and braking motor drive.
• Motor speed control by an external voltage.
• Stable motor direction change.
• Interfaces with CMOS devices.
• Built-in the thermal shut down circuit (165°C).
• Low standby current. (6.5mA)
KA3082N Connection Diagram
KA3082N
PDF/DataSheet Download
- Datasheet: KA3082N
- File Size: 92435 KB
- Manufacturer: FAIRCHILD [Fairchild Semiconductor]
- Click here to Download
