KDE0505PHV2.MS.A.GN

FAN 5VDC 50X15MM 0.8W 13CFM

product image

KDE0505PHV2.MS.A.GN Picture
SeekIC No. : 003443730 Detail

KDE0505PHV2.MS.A.GN: FAN 5VDC 50X15MM 0.8W 13CFM

floor Price/Ceiling Price

US $ 2.4~4.19 / Piece | Get Latest Price
Part Number:
KDE0505PHV2.MS.A.GN
Mfg:
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~10
  • 10~25
  • 25~50
  • 50~100
  • 100~250
  • 250~500
  • 500~1000
  • Unit Price
  • $4.19
  • $3.84
  • $3.49
  • $3.14
  • $2.88
  • $2.75
  • $2.58
  • $2.4
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/25

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Series: KDE Manufacturer: Sunon Fans
Fan Type: Tubeaxial Size / Dimension: Square - 50mm L x 50mm H x 15mm W
Voltage - Rated: 5VDC Power (Watts): 0.80W
Features: - RPM: 4700 RPM
Noise: 29 dB(A) Package / Case : SOP-20
Static Pressure: 0.170 in H2O (42.3 Pa) Air Flow: 13.0 CFM (0.368m³/min)
Termination: 2 Wire Leads Bearing Type: Vapo-Bearing?

Description

Manufacturer: Sunon Fans
Fan Type: Tubeaxial
Features: -
Termination: 2 Wire Leads
Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
Bearing Type: Vapo-Bearing?
Voltage - Rated: 5VDC
Air Flow: 13.0 CFM (0.368m³/min)
Power (Watts): 0.80W
Static Pressure: 0.170 in H2O (42.3 Pa)
Series: KDE
Size / Dimension: Square - 50mm L x 50mm H x 15mm W
RPM: 4700 RPM
Noise: 29 dB(A)


Parameters:

Technical/Catalog InformationKDE0505PHV2.MS.A.GN
VendorSunon Fans
CategoryFans, Thermal Management
Voltage - Rated 5VDC
Power (Watts)0.8W
Bearing TypeVapo-Bearing?
Size / DimensionSquare - 50mm L x 50mm H x 15mm W
Air Flow13 CFM
Features-
Termination2 Wire Leads
Fan TypeTubeaxial
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names KDE0505PHV2 MS A GN
KDE0505PHV2MSAGN
259 1346 ND
2591346ND
259-1346
