Part Number: L38812_1224856
Description: The UTC L388 12 contains all the necessary circuitry, amplifiers, detectors, comparators and control f...
- Table of contents:
L38812_1224856
-
Suppliers
DataSheet
General Description
L38812_1224856 General Description
The UTC L388 12 contains all the necessary circuitry, amplifiers, detectors, comparators and control functions to implement a high performance, voice-switched, "hands-free"function in an answering machine.
The UTC L 388 12 is designed for answering machines that are either powered from the telephone line or from a mains powered dc. supply.
Filtering of both the audio and control signals in both transmitter and receiver channels possible.
An external loudspeaker amplifier has to be used, normally the same as used for the answering machine.
L38812_1224856 Maximum Ratings
| PARAMETER | SYMBOL | RATINGS | UNIT |
| Speech switch supply current | ID | 10 | mA |
| Voltage Pin 1-14 | -0,5 ~ Vpin15+0.5 | V | |
| Operating temperature | Topr | -20 ~ +70 | |
| Storage temperature | Tstg | -55 ~ +125 |
L38812_1224856 Features
*Settable gain dynamics (25 or 50dB)
*Low power consumption, totally 1.0mA at 3.3V typical.
*Background noise compensation in the transmitting channel with hold function.
*Excellent noise performance.
*Both channel input amplifiers have balanced inputs.
*Minimum of external components needed for function.
*Low power consumption, totally 1.0mA at 3.3V typical.
*Background noise compensation in the transmitting channel with hold function.
*Excellent noise performance.
*Both channel input amplifiers have balanced inputs.
*Minimum of external components needed for function.
L38812_1224856 Connection Diagram
