MFG:STMICROELECTRONICSSEMI D/C:07+
MFG: STMICROELECTRONICSSEMI
D/C: 07+
Description: L6258E is a dual full bridge for motor control applica- tions realized in BCD technology, with the cap...
L6258E is a dual full bridge for motor control applica- tions realized in BCD technology, with the capability of driving both windings of a bipolar stepper motor or bidirectionally control two DC motors.
L6258E and a few external components form a com- plete control and drive circuit. It has high efficiency phase shift chopping that allows a very low current ripple at the lowest current control levels, and makes this device ideal for steppers as well as for DC mo- tors.The power stage is a dual DMOS full bridge ca- pable of sustaining up to 40V, and includes the diodes for current recirculation.The output current ca- pability is 1.2A per winding in continuous mode, with peak start-up current up to 1.5A. A thermal protection circuitry disables the outputs if the chip temperature exceeds the safe limits.
| Symbol | Parameter | Value | Unit |
| Vs | Supply Voltage | 45 | V |
| VDD | Logic Supply Voltage | 7 | V |
| Vref1/Vref2 | Reference Voltage | 2.5 | V |
| IO | Output Current (peak) | 1.5 | A |
| IO | Output Current (continuous) | 1.2 | A |
| Vin | Logic Input Voltage Range | -0.3 to 7 | V |
| Vboot | Bootstrap Supply | 60 | V |
| Vboot - Vs | Maximum Vgate applicable | 15 | V |
| Tj | Junction Temperature | 150 | °C |
| Tstg | Storage Temperature Range | -55 to 150 | °C |
L6258E
PDF/DataSheet Download
