LA-121 AK General Description


The LA-121 AK series are two-color, high luminance LED numerical displays designed to allow use even in bright locations. Red, green and orange displays
are possible.

LA-121 AK Maximum Ratings

Parametr
Symbol
Red
Green
Unit
LA-121MLA/MLK
LA-121MLA/MLK
Power dissipation
PD
900
750

Power dissipation
PD/seg
120(60)
100(50)

Forward current
IF
30
20

Peak forward current
IFP
80(1)
60(1)

Reverse voltage
VR
8(4)
8(4)

Operating temperature
Topr
-25~+75

Storage temperature
Tstg
-30~+85


(1)Pulse width 1ms duty 1/5
()is D.P value

LA-121 AK Features

·Height of character : 25.4 mm.
· Dimensions : 22.8 × 33 × 9 mm.
· A common anode configuration and a common cathode configuration are available.
· The package surface is painted black and the segments are milky white.
· High luminance, clear display.
· Red, green and orange displays are possible
