Part Number: LB-402 FP
Description: The LB-402 FP series were designed to meet the need for multi-digit numeric displays. Featuring excell...
- Table of contents:
LB-402 FP
-
Suppliers
DataSheet
General Description
LB-402 FP General Description
The LB-402 FP series were designed to meet the need for multi-digit numeric displays. Featuring excellent visibility, these two-digit LED numeric displays have a character height of 10 mm. A colored cover case is attached to the surface of the display.
LB-402 FP Maximum Ratings
| Parametr |
Symbol |
Red |
Orange |
Green |
Unit |
|
LB-402VF/VP |
LB-402DF/DP |
LB-402MF/MP | |||
| Power dissipation |
PD |
840 |
840 |
840 |
mA |
| Power dissipation |
PD/seg |
60 |
60 |
60 |
mW/seg |
| Forward current |
IF |
20 |
20 |
20 |
mA |
| Peak forward current |
IFP |
60 |
60 |
60 |
mA(1) |
| Reverse voltage |
VR |
5 |
5 |
5 |
V |
| Operating temperature |
Topr |
-25~+75 |
|||
| Storage temperature |
Tstg |
-30~+100 |
|||
(1)Pulse width 1ms duty 1/5
LB-402 FP Features
· Three colors are available: red, orange and green.
· Common anode and common cathode configurations are available.
·Each segment has independent pin connections making static drive possible.
· Excellent visibility.
Uniform brightness.
Wide view angle.
Character shapes cannot be seen
when not illuminated.
· Common anode and common cathode configurations are available.
·Each segment has independent pin connections making static drive possible.
· Excellent visibility.
Uniform brightness.
Wide view angle.
Character shapes cannot be seen
when not illuminated.
LB-20
PDF/DataSheet Download
- Datasheet: LB-20
- File Size: 71921 KB
- Manufacturer: ETC [ETC]
- Click here to Download
- ·LB-202BL
- ROHM [Rohm]
- High efficiency, two-digit numeric displays
- 61811 KB
- ·LB-203BL
- ROHM [Rohm]
- High efficiency, three-digit numeric displays
- 64131 KB
- ·LB-302FP
- ROHM [Rohm]
- High efficiency, two-digit numeric displays
- 60065 KB
- ·LB-303AK
- ROHM [Rohm]
- High efficiency, three-digit numeric displays
- 63568 KB
- ·LB-402
- ROHM [Rohm]
- High efficiency, two-digit numeric displays
- 62606 KB
- ·LB-402DN
- ROHM [Rohm]
- High efficiency, two-digit numeric displays
- 62606 KB
- ·LB-402FP
- ROHM [Rohm]
- High efficiency, two-digit numeric displays
- 60229 KB
- ·LB-403F1
- ROHM [Rohm]
- High efficiency, three-digit numeric displays
- 60140 KB
LB-402 FP Relative Products
LB-402 DN
The LB-402 DN series were designed to meet the need for multi-digit numeric displays. These LED numeric displays use GaAsP on GaP for the emitting aterial (with the exception of green) and are housed in an epoxy resin package. They are two-digit displays wit...
LB-402 CM
The LB-402 CM series are two-digit LED numeric displays with a character height of 10 mm. These displays were designed for use as counter displays, and are housed in a compact case of 14× 13 mm.
LB401
Silicon VDMOS and LDMOS transistors LB401 designed specifically for broadband RF applications. Suitable for Militry Radios, Cellular and Paging Amplifier Base Stations, Broadcast FM/AM, MRI, Laser Driver and others."Polyfet"TMprocess features low feedback an...
LB3803X
