LL-0283-20E

The LL-0283-20E is designed as one kind of compact, single phase, high current device that is very useful in power control systems. This "E" configuration is identical to our 283 series except that the ground coil has been eliminated for use in "Stand Alone" situations. The enclosure has also been modified to match a standard filter enclosure configuration.

The electrical and mechanical specifications of the LL-0283-20E can be summarized as:(1)Operating voltage = 115/250 Vac; (2)Operating current = 20, 30 Amp; (3)Operating frequency = 50/60Hz; (4)Operating temperature = -20 to 50 o C; (5)Diel. withstanding (line - case) = 1500 Vac; (6)Diel. withstanding (line - line) = 1500 Vdc; (7)Leakage current = 1.5 ma at 250 Vac, 60 Hz; (8)Max residual voltage after 1 sec. = 30 Volts; (9)Agency approvals = UL, CSA, VDE. If you want to know more information about the LL-0283-20E, please download the datasheet in www.seekic.com or www.chinaicmart.com .
