LM158AJ

The LM158AJ is one member of the LM158 family which is designed as the low power dual operational amplifier. Also this device consists of two independ-ent, high gain, internally frequency compensated which were designed specifically to operate from a single power supply over a wide range of voltages.

Features of the LM158AJ are:(1)internally f requency compensated ; (2)large DC voltage gain: 100dB ; (3)wide bandwidth (unity gain) : 1.1MHz (temperat-ure compensated) ; (4)very low supply current/OP (500mA) - essentially independent of supply voltage ; (5)low input bias current : 20nA (temperature compensated) ; (6)low input offset voltage: 2mV ; (7)low input offset current: 2nA ; (8)input common-mode voltage range includes ground ; (9)differential input voltage range equal to the power supply voltage ; (10)large output voltage swing 0v to (VCC 1.5V).

The absolute maximum ratings of the LM158AJ can be summarized as:(1)supply voltage: +32 V;(2)input voltage: -0.3 to +32 V;(3)differential input voltage: +32 V;(4)output short-circuit duration: infinite;(5)power dissipation: 500 mW;(6)operating free-air temperature range: -55 to +125;(7)storage temperature range:-65 to +150. If you want to know more information such as the electrical characteristics about the LM158AJ, please download the datasheet in www.seekic.com or www.chinaicmart.com .
