LM20154MH

The LM20154MH is a full featured 1 MHz synchronous buck regulator capable of delivering up to 4A of continuous output current. The device features internal over voltage protection (OVP) and over current protection (OCP) circuits for increased system reliability. It is designed to work well in multi-rail power supply architectures.

The features of LM20154MH can be summarized as:(1)Input voltage range 2.95V to 5.5V; (2)Accurate current limit minimizes inductor size; (3)96% peak efficiency at 1.0 MHz switching frequency; (4)Frequency synchronization output; (5)32 m integrated FET switches; (6)Starts up into pre-biased loads; (7)Output voltage tracking; (8)Peak current mode control; (9)Adjustable output voltage down to 0.8V; (10)Adjustable Soft-Start with external capacitor; (11)Precision enable pin with hysteresis; (12)Integrated OVP, UVLO, power good and thermal shutdown; (13)eTSSOP-16 exposed pad package.

The absolute maximum ratings of LM20154MH are:(1)Voltages from the indicated pins to GND,AVIN, PVIN, EN, PGOOD, SS/TRK, COMP, FB, SYNCOUT:-0.3V to +6V; (2)Storage Temperature:-65°C to 150°C; (3)Junction Temperature:150°C; (4)Power Dissipation:2.6W; (5)Lead Temperature (Soldering,10 sec):260°C; (6)Minimum ESD Rating: ±2kV; (7)PVIN, AVIN to GND:2.95V to 5.5V; (8)Junction Temperature:-40°C to + 125°C.

If you want to know more information such as the electrical characteristics about the LM20154MH, please download the datasheet in www.seekic.com or www.chinaicmart.com .
