Purchase LM22679EVAL, In-stock LM22679EVAL From SeekIC.

MFG:National Semiconductor  Category:Programmers, Development Systems

LM22679EVAL

LM2 Series Datasheet download

Five Points

Part Number: LM22679EVAL

Category: Programmers, Development Systems

MFG: National Semiconductor





Descriptions: BOARD EVALUATION FOR LM22679

Price Break

1

Unit Price

30.60000

Extended Price

30.60

(All prices are in USD) Prices for reference only
Urgent Purchase

LM22679EVAL General Description

BOARD EVALUATION FOR LM22679

LM22679EVAL Parameters

Technical/Catalog InformationLM22679EVAL
VendorNational Semiconductor
CategoryProgrammers, Development Systems
Board TypeFully Populated
Main PurposeDC/DC, Step Down
Regulator TopologyBuck
Outputs and Type1, Non-Isolated
Voltage - Output3.3V
Current - Output5A
Voltage - Input4.5 ~ 42V
Frequency - Switching500kHz
Power - Output16.5W
Utilized IC / PartLM22679
Supplied ContentsBoard
Lead Free StatusLead Not Applicable
RoHS StatusRoHS Not Applicable
Other Names LM22679EVAL
