LM358N

Slew Rate :
Output Current :
Number of Channels : 2
Packaging : Tube
Shutdown : No
Common Mode Rejection Ratio (Min) : 65 dB
Input Offset Voltage : 7 mV
Mounting Style : Through Hole
Maximum Operating Temperature : + 70 C
Operating Supply Voltage : 5 V, 9 V, 12 V, 15 V
Package / Case : DIP-8
Input Bias Current (Max) : 250 nA


Description

The LM358N is one of the LM35 series.The LM35 series are precision integrated-circuit temperature sensors, whose output voltage is linearly proportional to the Celsius (Centigrade) temperature. The LM35 thus has an advantage over linear temperature sensors calibrated in Kelvin, as the user is not required to subtract a large constant voltage from its output to obtain convenient Centigrade scaling. The LM35 does not require any external calibration or trimming to provide typical accuracies of ±1/4°C at room temperature and ±3/4°C over a full -55 to +150°C temperature range. Low cost is assured by trimming and calibration at the wafer level. The LM35's low output impedance,linear output, and precise inherent calibration make interfacing to readout or control circuitry especially easy. It can be used with single power supplies, or with plus and minus supplies. As it draws only 60 A from its supply, it has very low self-heating, less than 0.1°C in still air. The LM35 is rated to operate over a -55° to +150°C temperature range,while the LM35C is rated for a -40° to +110°C range (-10°with improved accuracy). The LM35 series is available packaged in hermetic TO-46 transistor packages, while the LM35C, LM35CA, and LM35D are also available in the plastic TO-92 transistor package. The LM35D is also available in an 8-lead surface mount small outline package and a plastic TO-220 package.

Features of the LM358N are:(1)Calibrated directly in  Celsius (Centigrade); (2)Linear + 10.0 mV/ scale factor; (3)0.5C accuracy guaranteeable (at +25C); (4)Rated for full .55 to +150 range; (5)Suitable for remote applications; (6)Low cost due to wafer-level trimming; (7)Operates from 4 to 30 volts; (8)Less than 60 A current drain; (9)Low self-heating, 0.08 in still air; (10)Nonlinearity only +-1/4 typical; (11)Low impedance output, 0.1 for 1 mA load.

The absolute maximum ratings of the LM358N can be summarized as:(1)Supply Voltage +35V to .0.2V; (2)Output Voltage +6V to .1.0V; (3)Output Current 10 mA; (4)Storage Temp:TO-46 Package, -60°C to +180°C TO-92 Package, -60°C to +150°C SO-8 Package, -65°C to +150°C TO-220 Package, -65°C to +150°C; (5)Lead Temp.:TO-46 Package,(Soldering, 10 seconds) 300°C.If you want to know more information such as the electrical characteristics about the BF904, please download the datasheet in www.seekic.com or www.chinaicmart.com.

Parameters:

Technical/Catalog Information	LM358N
Vendor	ON Semiconductor
Category	Integrated Circuits (ICs)
Packaging	Tube
Amplifier Type	General Purpose
Number of Circuits	2 - Dual
Package / Case	8-DIP
Slew Rate	0.6 V/s
Gain Bandwidth Product	1MHz
Current - Supply	1.5mA
Current - Output/Channel	40mA
Voltage - Supply, Single/Dual (±)	3 V ~ 32 V, ±1.5 V ~ 16 V
Output Type	-
-3db Bandwidth	-
Current - Input Bias	0.045A
Operating Temperature	0°C ~ 70°C
Voltage - Input Offset	2000V
Lead Free Status	Contains Lead
RoHS Status	RoHS Non-Compliant
Other Names	LM358N LM358N LM358NOS ND LM358NOSND LM358NOS
