LMV951

The LMV951 amplifier is capable of operating at supply voltages from 0.9V to 3V with guaranteed specs at 1V and 1.8V single supply.

The input common mode range extends to both power supply rails without the offset glitch and input bias current phase reversal inherent to most rail to rail input amplifiers.

Contrary to a conventional rail to rail output amplifier the LMV951 has a buffered output stage providing an open loop gain which is relatively unaffected by resistive output loading. At 1V supply voltage, the LMV951 is able to source and sink in excess of 35 mA and offers a gain bandwidth product of 2.7 MHz.

In shutdown mode the LMV951 consumes less than 50 nA of supply current.
