LN242RPH

Standard LED - Through Hole LED RED DIFFUSED 2x5MM RECT

product image

LN242RPH Picture
See larger image
SeekIC No. : 0060660 Detail

LN242RPH: Standard LED - Through Hole LED RED DIFFUSED 2x5MM RECT

LN242RPH Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
LN242RPH
Mfg:
Panasonic Electronic Components
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/5

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Illumination Color : Red Lens Color/Style : Diffused
LED Size : 5 mm x 2 mm Packaging : Bulk

Description

Luminous Intensity :
Wavelength/Color Temperature :
Viewing Angle :
Forward Current :
Forward Voltage :
Illumination Color : Red
Packaging : Bulk
Lens Color/Style : Diffused
LED Size : 5 mm x 2 mm


Specifications

Lighting Color
PD(mW)
IF(mA)
IFP(mA)*
VR(V)
Topr(°C)
Tstg(°C)
Red
70
25
150
4
-25 ~ +85
-30 ~ +100
Green
90
30
150
4
-25 ~ +85
-30 ~ +100
Amber
90
30
150
4
-25 ~ +85
-30 ~ +100
Orange
90
30
150
3
-25 ~ +85
-30 ~ +100
IFP  duty 10%  Pulse width 1 msec. The condition of IFP is duty 10%, Pulse width 1 msec


Parameters:

Technical/Catalog InformationLN242RPH
VendorPanasonic - SSG
CategoryOptoelectronics
ColorRed
Lens Style/SizeRectangle, 5mm x 2mm
Millicandela Rating0.4mcd
Voltage - Forward (Vf) Typ2.2V
Wavelength - Dominant700nm
Wavelength - Peak700nm
Current - Test20mA
Viewing Angle-
Lens TypeDiffused, Red Tinted
Luminous Flux-
Package / CaseRadial
Mounting TypeThrough Hole
PackagingBag
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names LN242RPH
LN242RPH
P14223 ND
P14223ND
P14223
