LN417YPH, US $ .07-.07, LN417YPH DataSheet download, circuit diagram from SeekIC.com

See larger image

SeekIC No. : 003613527 Detail

LN417YPH: LED AMBR DIFFUSED 1.8X5.3MM RECT

LN417YPH Data Sheet

US $ .07~.07 / Piece | Get Latest Price

Part Number:: LN417YPH
Mfg:
Supply Ability:: 5000

Price Break

Qty
0~1700

Unit Price
$.07

Processing time
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/4/18

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

LN411YP evaluate
US $.06 - .21 / Piece

LED AMBER 1.8 X 3.5
LN413YPP evaluate
Specifications Lighting Color PD(mW) IF(mA) IFP(mA)* VR(V) Topr(°C) Tstg(°C) Red 70...
LN416YP evaluate
Specifications Lighting Color PD(mW) IF(mA) IFP(mA)* VR(V) Topr(°C) Tstg(°C) Red 70...

Product Details

Quick Details

Series:	-	Manufacturer:	Panasonic Electronic Components - Semiconductor Products
Color:	Amber	Millicandela Rating:	1.5mcd
Voltage - Forward (Vf) Typ:	2.2V	Current - Test:	20mA
Wavelength - Dominant:	-	Wavelength - Peak:	590nm
Viewing Angle:	-	Lens Type:	-
Package / Case :	Micro	Lens Style/Size:	Rectangle with Flat Top, 5.3mm x 1.8mm
Package / Case:	Radial	Size / Dimension:	-
Height:	8.00mm	Mounting Type:	Through Hole

Description

Series: -
Current - Test: 20mA
Voltage - Forward (Vf) Typ: 2.2V
Wavelength - Dominant: -
Viewing Angle: -
Lens Type: -
Size / Dimension: -
Package / Case: Radial
Mounting Type: Through Hole
Packaging: Bulk
Color: Amber
Manufacturer: Panasonic Electronic Components - Semiconductor Products
Wavelength - Peak: 590nm
Millicandela Rating: 1.5mcd
Lens Style/Size: Rectangle with Flat Top, 5.3mm x 1.8mm
Height: 8.00mm

Parameters:

Technical/Catalog Information	LN417YPH
Vendor	Panasonic - SSG
Category	Optoelectronics
Color	Amber
Lens Style/Size	Rectangle, 5.3mm x 1.8mm
Millicandela Rating	1.5mcd
Voltage - Forward (Vf) Typ	2.2V
Wavelength - Dominant	590nm
Wavelength - Peak	590nm
Current - Test	20mA
Viewing Angle	130°
Lens Type	Diffused, Amber Tinted
Luminous Flux	5 mlm
Package / Case	Radial
Mounting Type	Through Hole
Packaging	Bulk
Lead Free Status	Contains Lead
RoHS Status	RoHS Non-Compliant
Other Names	LN417YPH LN417YPH P611 ND P611ND P611
