LND393

The LND393 consists of two independent precision voltage comparators with an offset voltage specification as low as 2.0 mV max for two comparators. They are specifically designed to operate from a single power supply over a wide range of voltages. In addition, the comparators have the unique ability in that the input common-mode voltage range includes ground, while operated from a single power supply voltage. Operation from split power supplies is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage.

Application areas include limit comparators, simple analog to digital converters, pulse, squarewave and time delay generators: wide range VCO, MOS clock timers, multi-vibrators and high voltage digital logic gates. The LND393 was designed to directly interface with TTL and CMOS. When the LND393 is operated from both plus and minus power supplies, it will directly interface with MOS logic where their low power drain is a distinct advantage over standard comparators.
