LNJ211R8ARA, US $ .09-.33, LNJ211R8ARA DataSheet download, circuit diagram from SeekIC.com

See larger image

SeekIC No. : 003614234 Detail

LNJ211R8ARA: LED RED FACE UP 1206

LNJ211R8ARA Data Sheet

US $ .09~.33 / Piece | Get Latest Price

Part Number:: LNJ211R8ARA
Mfg:
Supply Ability:: 5000

Price Break

Qty
0~1
1~25
25~100
100~250
250~500
500~1000

Unit Price
$.33
$.22
$.18
$.15
$.12
$.09

Processing time
15 Days
15 Days
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/4/27

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Product Details

Quick Details

Series:	-	Manufacturer:	Panasonic Electronic Components - Semiconductor Products
Color:	Red	Millicandela Rating:	7mcd
Voltage - Forward (Vf) Typ:	1.72V	Current - Test:	10mA
Supply Current (Max) :	0.0023 mA	Wavelength - Dominant:	-
Wavelength - Peak:	660nm	Viewing Angle:	-
Lens Type:	Diffused, Tinted	Lens Style/Size:	Round with Domed Top, 1.7mm
Package / Case:	1206 (3216 Metric)	Size / Dimension:	3.20mm L x 1.60mm W
Height:	1.10mm	Mounting Type:	Surface Mount

Description

Series: -
Mounting Type: Surface Mount
Packaging: Cut Tape (CT)Alternate Packaging
Current - Test: 10mA
Color: Red
Wavelength - Dominant: -
Viewing Angle: -
Lens Type: Diffused, Tinted
Package / Case: 1206 (3216 Metric)
Size / Dimension: 3.20mm L x 1.60mm W
Height: 1.10mm
Wavelength - Peak: 660nm
Manufacturer: Panasonic Electronic Components - Semiconductor Products
Millicandela Rating: 7mcd
Voltage - Forward (Vf) Typ: 1.72V
Lens Style/Size: Round with Domed Top, 1.7mm

Specifications

Lighting Color	P_D(mW)	I_F(mA)	I_FP(mA)*	V_R(V)	T_opr()	T_stg()
Red	60	20	100	3	-30 ~ +85	-40 ~ +100
Green	60	20	100	4	-30 ~ +85	-40 ~ +100
Amber	60	20	100	4	-30 ~ +85	-40 ~ +100

IFP,duty 10%,Pulse width 1 msec. The condition of IFP is duty 10%, Pulse width 1 msec

Parameters:

Technical/Catalog Information	LNJ211R8ARA
Vendor	Panasonic - SSG (VA)
Category	Optoelectronics
Color	Red
Lens Style/Size	Round, 1.7mm
Millicandela Rating	7mcd
Voltage - Forward (Vf) Typ	1.72V
Wavelength - Dominant	660nm
Wavelength - Peak	660nm
Current - Test	10mA
Viewing Angle	170°
Lens Type	Diffused, Red Tinted
Luminous Flux	40 mlm
Package / Case	1206 (3216 metric)
Mounting Type	Surface Mount
Packaging	Cut Tape (CT)
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	LNJ211R8ARA LNJ211R8ARA P11141CT ND P11141CTND P11141CT
