Part Number: LS5018B



MFG: ST

Package Cooled: DIP



Description: The LS50xxB series has been designed to protect telecommunication equipment against lightning and transients induced by...


Urgent Purchase

LS5018B General Description


The LS50xxB series has been designed to protect telecommunication equipment against lightning and transients induced by AC power lines.

Its high surge current capability makes the LS50xxB a reliable protection device for very exposed equipment, or when series resistors are very low.

LS5018B Maximum Ratings

Symbol Parameter Value Unit
IPP Peak pulse current 10/1000 s
8/20 s		 100
250		 A
ITSM Non repetitivesurge peak on-state
current		 tp = 20ms 50 A
dI/dt Critical rate of rise of on-state current Non repetitive 100 A/s
dV/dt Critical rate of rise of off-state voltage VRM 5 kV/s
Tstg
Tj		 Storage and operatingjunction temperature range 40 to + 150
150
TL Maximum lead temperature for soldering during 10s 230

LS5018B Features

`BIDIRECTIONALCROWBAR PROTECTION.
`BREAKDOWNVOLTAGESRANGE: 18V, 60V and 120V.
`HOLDINGCURRENT= 200mA min.
`HIGH SURGE CURRENT CAPABILITY IPP = 100A 10/1000s

LS5018B Connection Diagram

LS5018B Connection Diagram
