General Description
LSA2825 General Description
The LSAX82X is a compact nalog coaxial pigtailed laser ransmitter, operating in the 300 nm wavelength region and oupling light to single mode iber.
The device features a high eliability SMQW laser diode and ear facet monitor photodiode. hese are electrically connected o four pins in an industrystandard onfiguration.
Environmental performance is esigned to be compatible with he requirements of Bellcore's A-NWT-000983 document.
If the specific arrangement or erformance you require is not isted, please contact your local epresentative, as our highly lexible design and manufacturing rocesses allow both physical and lectro-optical customization to eet your needs. aser
LSA2825 Maximum Ratings
Absolute limiting (maximum) ratings mean that no catastrophic damage will occur if the product is subjected to these ratings for short periods, rovided that each limiting parameter is in isolation and all other parameters have values within the performance specification. It should not be ssumed that limiting values of more than one parameter can be applied to the product at the same time.
|
Parameter |
Symbol |
Test Condition |
Limits |
Units | |
|
Min. |
Max. | ||||
| Laser Forward Current |
If |
DC |
120 |
mA | |
| Laser Reverse Voltage |
Vlr |
DC |
2 |
V | |
| Photodiode Reverse Voltage |
Vr |
DC |
20 |
V | |
| Photodiode Forward Current |
Ipf |
DC |
1 |
mA | |
| Operating Temperature |
Tc |
Temperature measured at case |
-40 |
+85 |
°C |
| Storage Temperature |
Ts |
-40 |
+85 |
°C | |
| Relative Humidity |
RH |
noncondensing |
%RH | ||
| Fiber Pull Strength | Three times; 10 sec. |
10 |
N | ||
| Mechanical Shock | MIL-STD-883D, Method 2002, Condition A |
500 |
G | ||
| Vibration | MIL-STD-883D, Method 2007, Condition A |
20 |
G | ||
LSA2825 Features
• Compact Coaxial Package
• Strained Multi Quantum ell (SMQW) Laser Chip
• Low Thresholds Current and perating Currents
• Wide Operating Temperature 40°C to +85°C
• Optical Power May Be ustomized up to 2 mW
• Convenient Variety of inout and Mounting Flange tions
• Strained Multi Quantum ell (SMQW) Laser Chip
• Low Thresholds Current and perating Currents
• Wide Operating Temperature 40°C to +85°C
• Optical Power May Be ustomized up to 2 mW
• Convenient Variety of inout and Mounting Flange tions
LSA2825 Typical Application
• CATV/CCTV
• Return Path Links
• LANS/WANS
• Return Path Links
• LANS/WANS
