M12L64164A

 JEDEC standard 3.3V power supply
 LVTTL compatible with multiplexed address
  Four banks operation MRS cycle with address key programs
         CAS Latency (2 & 3)
         Burst Length (1, 2, 4, 8 & full page)
         Burst Type (Sequential & Interleave)
 All inputs are sampled at the positive going edge of the system clock
 DQM for masking
  Auto & self refresh
 15.6 s refresh interval

The M12L64164A is 67,108,864 bits synchronous high data rate Dynamic RAM organized as 4 x 1,048,576 words by  16 bits. Synchronous design allows precise cycle controls with the use of system clock I/O transactions are possible on  every clock cycle. Range of operating frequencies, programmable burst length and programmable latencies allow the same
device to be useful for a variety of high bandwidth, high performance memory system applications.
