General Description
M45028 General Description
The M45026 is a CMOS ASIC encoder. It will en-code 9 parallel inputs and serially transmit them to the output when TE depressed. These address inputs are 3 states i.e. LOW (0)OPEN (X) and HIGH (1).
M45028 Maximum Ratings
| Parameter | Rating | Unit |
| Supply Voltage | -0.3 to 15 | V |
| Input Voltage | -0.2~VDD +0.2 | V |
| Operating Temperature | -20 to 75 | |
| Storage Temperature | -50 to 125 |
M45028 Features
RC oscillator.
39 =19,683 codes, "0","X","1" Tri-states.
Minimum two transmission words.
M45028 Typical Application
Car/home alarm system, garage control etc..
M45028 Connection Diagram
M45028
